OPERATING INSTRUCTIONS
CASE HYDRAULIC COUPLER Template Name: OM_1_col Template Date: 1994_04_29
Installing a Bucket or Attachment IMPORTANT: Before installing a bucket or attachment, make sure the mounting area of the bucket and Case coupler is clean.
4. Look at the engagement indicators. Both indicators must be down in the green zone.
1. Make sure the hydraulic coupler control is pulled up.
1
TRIM THIS EDGE
B4054890
IMPORTANT: Raise and dump the bucket. Make sure both wedges are completely engaged. B4051690
1. HYDRAULIC COUPLER CONTROL
Alt= to hide template information Alt+ to display template information
2. Fasten seat belt, lower seat bar, start the engine and move the machine forward and pick up the bucket. Rotate the bucket back.
1
1. WEDGES
B4047190
Removing Bucket 1. Raise the bucket 25 to 50 mm (1 to 2 inches) above the ground. 2. Pull the hydraulic coupler control completely up. B4046790
3. In one movement, rotate the bucket forward and back out of the attachment.
3. Push the hydraulic coupler control down to the ENGAGE position. 68
