OPERATING INSTRUCTIONS
Installing a Bucket or Attachment IMPORTANT: Read the manufacturers instruction manual for attachments not included in this manual. DO NOT use attachments that are not approved by CASE. The use of additional equipment or accessories that are not authorized by CASE will invalidate CE certification to safety requirements. Any modification of the machine with a view to adapting any such equipment or accessory that is not authoriized in this manual must receive CASE approval. IMPORTANT: Before installing a bucket or attachment, make sure the mounting area of the bucket and Case Coupler is clean. 3. Push both Case Coupler levers down to hold the bucket or attachment in place. Make suere the two wedges are completely down and engaged. TRIM THIS EDGE
1. Pull both Case Coupler levers up to the vertical position. Start the engine and tilt the Case Coupler forward.
CASE COUPLER LEVERS
Alt= to hide template information Alt+ to display template information
CASE COUPLER
B4132388
Removing a Bucket or Attachment 1. Lift both Case Coupler levers up to the vertical position to disengage the wedges. 2. Fasten seat belt, lower seat bar, start the engine and rotate the bucket or attachment out. 3. Lower the bucket or attachment to the ground and slowly back machine/Case Coupler away from the bucket or attachment.
B4132288
67
TRIM THIS EDGE
RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
B4132188
2. Move the machine forward and pick up the bucket or attachment. Tilt the bucket or attachment back.
