OPERATING INSTRUCTIONS
OPERATING THE LOADER Template Name: OM_1_col Template Date: 1994_04_29 TRIM THIS EDGE
!
WARNING: When you operate, always keep all parts of your body inside the operators compartment. Then, before you leave the operators seat, always lower the loader bucket or attachment to the ground and stop the engine. You can be injured or killed if you do not follow these instructions. SA010
!
WARNING: During loader operations, keep the loaded bucket as low as possible. This low position lets you see in front of the machine and gives better machine balance. SA011
!
WARNING: Reduce the machine speed when working on rough ground. The machine can roll over if you drive too fast on rough ground. SA012
!
WARNING: Raised equipment on the machine without an operator can cause injury or death. Before you leave the operators compartment, always support or lower the equipment (backhoe, blade, boom, bucket, etc.) to the ground and stop the engine. CM105
Filling and Dumping the Bucket
Alt= to hide template information Alt+ to display template information
1. Lower the lift arms against the stops, increase the engine speed to full throttle an enter the stockpile at about 1/4 speed.
3. Carry the load low to the dump area.
BS99B110
4. When in the dump area, raise and dump the bucket. Keep all movements smooth.
BS99B109
2. Roll back and raise the bucket.
BS99B111 BS99B112
64
