IMPORTANT: If you must temporarily park the machine on a hillside, put the front of the machine toward the bottom of the hill. Make sure the machine is behind an object that will not move. 1. Park on level ground and lower the loader bucket to the ground.
8. After the engine starts, check the instruments to make sure the indications are correct. Run the engine at about 1/4 throttle until the engine coolant is warm.
Engine Speed
3. Turn the key to OFF to stop the engine.
Do not run the engine at idle speed for long periods. This can cause a low operating temperature. Low operating temperature can cause acids and deposits in the engine oil. It is recommended that you run the engine at full throttle when operating conditions permit and when safe.
4. Remove the key raise the seat bar and release the seat belt. Always use the hand rails and steps when leaving. NOTE: The parking latch is engaged automatically.
IMPORTANT: When you operate the backhoe, it is recommended that you run the engine at 1/2 throttle.
!
WARNING: Jumping on or off the machine can cause an injury. Always face the machine, use the hand rails and steps, and get on or off the machine slowly. SA038
ROTATING BEACON Observe local laws when using the rotating beacon. The electrical socket for connecting the rotating beacon can be used for a service inspction lamp also
1 1. ELECTRICAL SOCKET
57
TRIM THIS EDGE
RIGHT PAGE
H02114
TRIM THIS EDGE
2. Run the engine at 1/2 speed for two or three minutes, if the engine has been working at full load. This procedure will cool the engine parts evenly.
Template Name: OM_1_col Template Date: 1994_04_29
Parking the Machine and Stopping the Engine
IMPORTANT: Do not operate the starter motor more than 10 to 15 seconds at one time. Let the starter motor cool for three minutes before you actuate the starter motor again. While the starter motor is engaged, white or black smoke must seen at the exhaust pipe. If no smoke is seen, check the fuel supply.
Alt= to hide template information Alt+ to display template information
OPERATING INSTRUCTIONS
