SAFETY/DECALS/HAND SIGNALS
REAR WINDOW (If Equipped) Template Name: OM_1_col Template Date: 1994_04_29
If by accident the front of the machine becomes blocked so that you can not exit through the front of the machine, you can exit through the rear of the machine after removing the rear window. Do the following: 1. Turn the key switch to OFF. 2. Raise the seat bar. 3. Release the seat belt. 4. Locate the pull ring attached to the moulding filler strip of the rear window.
1
5. Pull the ring to remove the filler strip. 6. Push the rear window out. TRIM THIS EDGE
7. Exit the machine through the rear opening.
2
1. PULL RING 2. FILLER STRIP
