LUBRICATION/FILTERS/FLUIDS
Service Specifications Coolant Capacity............................................................ 17 litres (3.7 U.K. gallons) Reservoir Coolant Level Check Interval .....................Every 10 Hours of Operation Radiator Coolant Level Check Interval.....................Every 250 Hours of Operation Check and Tighten Coolant Hose Clamps ...............Every 250 Hours of Operation Coolant System Change Interval ...........................Every 2000 Hours of Operation or Once Every Year Thermostat .................................................................... 83 to 95˚C (181˚ to 203˚F)
!
WARNING: Hot coolant can spray out if radiator cap is removed. To remove radiator cap: Let system cool, turn to first notch, then wait until all pressure is released. Scalding can result from fast removal of radiator cap. Check and service engine cooling system according to maintenance SA023 instructions.
Coolant Solution
TRIM THIS EDGE
Radiator Cap ................................................................................. 103 kPa (15 psi)
Alt= to hide template information Alt+ to display template information
ENGINE COOLING SYSTEM
NOTE: After you fill the cooling system, mix the ethylene glycol and water completely by running the engine at operating temperature for approximately five minutes. This procedure must be done when the machine is in temperatures below 0˚C (32˚F).
109
TRIM THIS EDGE Rac 9-11534 RIGHT PAGE
Template Name: OM_1_col Template Date: 1997_02_06
A mixture of 50% ethylene glycol and 50% water must be used in this machine. This mixture is used if the lowest ambient temperature is above -37˚C (-34˚F). It is recommended that ethylene glycol and water be used in your machine all year.
