FILTERSYSTEME / FILTER SYSTEMS
47
Spalt Active Die mechanischen Grobschmutzfilter FIAP Spalt Active ermöglichen über das großflächige Hochleistungsspaltsieb (FIAP SpaltSieb Active) eine Reinigung des Teichwassers von Feststoffen ab 300 Mikron. Durch diese wartungsarmen und effektiven Vorfilter ist die Entfernung von Schmutzpartikeln aus dem Wasserkreislauf ein Kinderspiel. Die nachfolgenden biologischen Filtermedien werden entlastet und es kann eine effektive biologische Wasseraufbereitung stattfinden. FIAP Spalt Active Filter eignen sich perfekt in Kombination mit dem FIAP Modul Active Filtersystem. • • • • • • • • • •
Mechanische Wasseraufbereitung Sauerstoffanreicherung durch FIAP SpaltSieb Active Grobschmutzentfernung durch Hochleistungsspaltsieb (300 Mikron) Perfekte Kombination mit FIAP Modul Active Filtersystem Herausragende Schmutzentfernung größer 0,3 mm Energie- und wassersparend Integrierter Schmutzablauf Einfache Installation und Wartung Pump- und Schwerkraftversion Premium Qualität aus Edelstahl
2849 2850 2851
The low-maintenance and effective pre-filters FIAP Spalt Active make the removal of dirt particles from the water cycle a breeze. With their large high-performance wedge wire sieve (FIAP SpaltSieb Active), these mechanical coarse dirt filters facilitate the removal of solids from 300 microns on from your pond water. Thereby, an effective biological water treatment can proceed without overloading subsequent biological filter media. FIAP Spalt Active filters are ideal in combination with the FIAP Module Active Filter System. • • • • • • • • • •
2852
Mechanical water treatment Oxygen enrichment by FIAP SpaltSieb Active Removal mud by high-performance wedge wire screen (300 Micron) Perfect combination with FIAP Module Active filter system Excellent dirt removal of particles larger than 0,3 mm Energy- and water-saving Integrated waste outlet Ersatzteilliste / Zubehör: Easy installation and maintenance Spare parts / fittings: Pump and gravity version Art. Nr. Bezeichnung Premium quality made of stainless steel
2853 2854 UVP MSRP
Art. No.
Specification
2850-1
FIAP SpaltSieb Active 8.000 FIAP wedge wire screen 8.000
299,00 €
2851-2
FIAP SpaltSieb Active 12.000 FIAP wedge wire screen 12.000
299,00 €
2853-2
FIAP SpaltSieb Active 22.000 FIAP wedge wire screen 22.000
399,00 €
2853-3
FIAP Reduzierung DN 150 / DN 100 FIAP reduction DN 150 / DN 100
19,90 €
2858
FIAP Pumpanschluss DN 100 / DN 50 FIAP pump adapter DN 100 / DN 50
99,00 €
2858-1
FIAP Pumpanschluss DN 100 / Tülle 32 / 40 / 50 mm FIAP pump adapter DN 100 / tail 32 / 40 / 50 mm
99,00 €
2859
FIAP Pumpanschluss DN 150 / DN 50 FIAP pump adapter DN 150 / DN 50
99,00 €
2859-1
FIAP Pumpanschluss DN 150 / Tülle 32 / 40 / 50 mm FIAP pump adapter DN 150 / tail 32 / 40 / 50 mm
99,00 €
Art. Nr. Art. No.
Bezeichnung Specification
Ausführung Construction
Wasserdurchsatz l / h Anschuss Zulauf / Ablauf Water Flow l / h Connection Inlet / Outlet
Abmessung mm Dimension mm
Gewicht kg Weight kg
UVP MSRP
2850
FIAP Spalt Active 8.000 FIAP wedge wire screen filter 8.000
Pumpversion pumped version
8.000
DN 100 / DN 100
400 x 500 x 550 25,2
1.190,00 €
2849
FIAP Spalt Active 8.000 FIAP wedge wire screen filter 8.000
Schwerkraftversion 8.000 gravity version
DN 100 / DN 100
400 x 500 x 550 25,2
1.290,00 €
2851
FIAP Spalt Active 12.000 FIAP wedge wire screen filter 12.000
Pumpversion pumped version
12.000
DN 100 / DN 100
625 x 250 x 850 29,0
1.190,00 €
2852
FIAP Spalt Active 12.000 FIAP wedge wire screen filter 12.000
Schwerkraftversion 12.000 gravity version
DN 100 / DN 100
625 x 250 x 850 29,0
1.290,00 €
2853
FIAP Spalt Active 22.000 FIAP wedge wire screen filter 22.000
Pumpversion pumped version
22.000
DN 150 / DN 150
625 x 500 x 850 42,0
1.490,00 €
2854
FIAP Spalt Active 22.000 FIAP wedge wire screen filter 22.000
Schwerkraftversion 22.000 gravity version
DN 150 / DN 150
625 x 500 x 850 42,0
1.590,00 €
