Darley Portable Pumps 35 HP HGE 35V 4 Stroke gasoline Engine Booster Reel Multiple Hand Lines Wildland/Attack Fire Suppression Control Panel: Mounted with engine controls and pressure gauge
Features: Aluminum alloy casing and discharge valve, aluminum alloy gear case & engine adapter, stainless steel shaft, skid base, helicle gears, discharge check valve, throttle, exhaust primer, 6 gallon plastic fuel tank, bronze impeller and seal ring, mechanical seal, electric start, flywheel alternator, fuel and oil pump filters, engine is a 35 HP Briggs air cooled, V-Twin, OHV, 4 cycle. Options: Anodized pump casing is available to reduce the weight of the pump.
Model HGE 35V (Air-Cooled)
Uses Performance Inlet Outlet Dimensions Weight Price High Vol. 500 gpm @ 50 psi Assem. #1 - 4" NPT 3" NPT Length: 29.5" 330 lbs. Assem. #1 - $8,360.00 Med. Press. 300 gpm @ 105 psi Assem. #2 - 4" NH 1-21/2" & 2-11/2"NPT Width: 27" (149.7 kg) Assem. #2 - $8,940.00 100 gpm @ 170 psi Assem. #3 - 4" NH 2-21/2" NH Height: 31" Assem. #3 - $9,510.00
64 HP
Powerful 64 hp engine
HE 64RP “Hercules” & HE 64RS “Hercules”
PUMPS
Dependable Rotax engine Booster tank fill Transfer and supply Multiple hand lines Wildland/Attack fire suppression
Ask abo u marine t our version !
Features: 64 HP Rotax 582, 2 cylinder, 2-cycle, liquidcooled, 12-volt electric start and recoil rope start back-up, 6 gal. fuel tank, hose and adapter, 170W lighting and recharging coil, aluminum alloy casing, bronze impeller and seal ring, stainless steel impeller shaft, mechanical seal, belt driven rotary primer, heat exchanger with thermal protection circuit, skid mounted, control panel with governor, ignition switch and compound pressure gauge, loss of prime shutdown. Options: Electric governor required for performance above 200 psi. Call for additional options.
Model Uses Performance HE 64RP Performance 575 gpm @ 100 psi Hercules 320 gpm @ 200 psi (Portable) 165 gpm @ 250 psi HE 64RS Skid Mounted - Call for details
302
HE 64RS Hercules (Skid Version Shown)
1.800.323.0244 | www.edarley.com/pumps
Portable
Inlet 4" NH
Outlet 2"-1/4 Turn Self-Locking 21/2" NH
Dimensions Length: 34" Width: 30" Height: 26"
Weight 225 lbs. (102 kg)
Price $18,090.00
$16,630.00
